Cortex-R52 System Details

Corellium Atlas provides 1 board model(s) in the Cortex-R52 System family.

Cortex-R52 System​

Board Image

  • Cortex-R52 System is generally available.
  • Supports connecting with the GNU Project Debugger.
  • Supports taking snapshots while the device is running.

Cortex-R52 System Configuration​

  • Defaults to 1 cores configurable between 1 and 4.
  • Defaults to 2048 KB of ram.
  • Supports changing CPU/RAM allocations on reboot.
  • Supports setting custom options before device boot.
  • Supports uploading a custom kernel.
  • Supports setting boot args.
  • Supports uploading custom firmware.

Cortex-R52 System Storage​

  • It has no storage partitions.

Cortex-R52 System I/O​

  • Supports vMMIO.
  • It has 4 serial ports available via dropdown named:
    • uart0-cons named UART-9C090FFF of type console.
    • uart1-cons named UART-9C0A0FFF of type console.
    • uart2-cons named UART-9C0B0FFF of type console.
    • uart3-cons named UART-9C0C0FFF of type console.
